An open-access interactive thermodynamic simulation workbench and digital psychrometric chart designed for undergraduate mechanical engineering and building science education. The simulator implements ASHRAE Hyland-Wexler formulations to model moist air properties across barometric pressures from sea level to 10,000 feet. Users can input any two independent psychrometric state properties (dry-bulb temperature, wet-bulb temperature, relative humidity, dew point, or humidity ratio) to solve enthalpy, specific volume, and vapor pressure in real time with dynamic SVG state-point plotting.
